AVENTICS ED12 Series Dynamic Direct Acting Pressure Regulator, 0-10 V, 0.5 to 8 bar, 5-Pin M12 Plug to Socket
Representative photo. Please check item description for details.

AVENTICS ED12 Series Dynamic Direct Acting Pressure Regulator, 0-10 V, 0.5 to 8 bar, 5-Pin M12 Plug to Socket

https://www.branom.com/web/image/product.template/207911/image_1920?unique=c26756c
(0 review)

The AVENTICS ED07 direct acting pressure regulator offers proportional pressurization and the exhaust valves are controlled seperately to deliver dynamic control for the most demanding applications.

Features

  • Type: Poppet valve
  • Certificates: CE declaration of conformity
  • Working pressure min.: 0.5 bar
  • Working pressure max: 8 bar
  • Min. ambient temperature: 5 °C
  • Max. ambient temperature: 50 °C
  • Medium: Compressed air
  • Nominal flow Qn: 2600 l/min
  • Control: Analog
  • DC operating voltage: 24 V
  • Hysteresis: < 0,03 bar
  • Mounting orientation: α = 0 ... 90° ±β = 0 ... 90°
  • Permissible ripple: 5%
  • Max. power consumption: 1400 mA
  • Protection class: IP65
  • Electrical connection: Plug
  • Electrical connection: M12
  • Electrical connection: 5-pin
  • Signal connection: input and output
  • Signal connection: Socket
  • Signal connection: M12
  • Signal connection: 5-pin
  • Actual output value: 0 ... 10 V
  • Nominal input value: 0 ... 10 V
  • Regulation range min.: 0 bar:

$ 4,087.46 4087.46 USD $ 4,087.46

$ 4,087.46

Not Available For Sale

    This combination does not exist.

    Contact Us
    Product Datasheets

    Datasheet 1
