Representative photo. Please check item description for details.
AVENTICS AS1-SSU Series Electric Filling Unit, 24 VDC, G 1/4, Left Air Supply, 2.5 to 10 bar, 3/2 Directional
Features
- Activation: Electrically
- Nominal flow Qn: 1300 l/min
- Compressed air connection: G 1/4
- Working pressure min.: 2.5 bar
- Working pressure max: 10 bar
- DC operating voltage: 24 V
- Sealing principle: Soft Seal
- Pilot: Internal
- Connection type: Pipe connection
- Parts: 3/2-directional valve, Filling valve
- Can be assembled into blocks: Can be assembled into blocks
- basic valve with electrical connector: Basic valve with pilot valve
- Type: Poppet valve
- Min. ambient temperature: -10 °C
- Max. ambient temperature: 50 °C
- Medium: Compressed air, Neutral gases
- Max. particle size: 25 µm
- Compressed air connection, exhaust: G 1/4
- Air supply: left
- Nominal flow Qn 1 to 2: 1300 l/min
- Nominal flow Qn 2 to 3: 380 l/min
- Power consumption DC: 2 W
- Duty cycle: 100 %
- Protection class with connection: IP65
- Electrical connection type 2: Plug:
