Danfoss Vacon NXC
Product Group: (NXC) NXC Frequency Converter
Current: (1180) (1180) 1180 Amp
Mains voltage: (6-) (6-) 525-690 Vac (640-1100Vdc)
Control Keypad: (A) (A) Alpha-numeric display
Enclosure: (2) (2) IP21/NEMA1
EMC Emission levels: (T) (T) IEC61800-3 f. IT networks
Brake Chopper: (0) (0) No Brake
Electrical Modification: (R) (R) AFE
Mechanical Modification: (S) (S) Standard air cooled drive
Card Modification: (G-) (G-)FiberConnect+Varnished PCB
Option Slot A: (A9) A9,OPTA1 with 2,5mm2 conn.
Option Slot B: (A2) A2,2RO(NO/NC)
Option Slot C: (A7) A7,Double HTLwiderng,6DI,2DO
Option Slot D: (D2) D2,SysBus(1fiber) + isol.CAN
Option Slot E: (CI) CI,Modbus/TCP
Input Device: (+ILS) (+ILS) Load switch
Circuit Breaker for AFE: (+ICB) (+ICB) Circuit Breaker
Motor operator for IBC: (+AMO) (+AMO) Motor Operator
Common Mode Choke: (+OCM) (+OCM) Common Mode Choke(M)
Output Filters: (+ODU) (+ODU) dU/dt Output Filters
Emergency Stop: (+DEP) (+DEP) Emergency Stop
Control Relay: (+ACR) (+ACR) Control Relay
Aux Transformer: (+AT2) (+AT2) Aux. Transformer(750VA)
Power Supply 24VDC 2.5A: (+ADC) (+ADC) Power Supply 24VDC 2.5A
0-1-START (MC oper.): (+DCO) (+DCO) 0-1-START (MC oper.)
Local / Remote -switch: (+DRO) (+DRO) Local / Remote -switch
External Terminals: (+TID) (+TID) External Terminals (70)
Ctrl. V Terminals: (+TUP) (+TUP) Ctrl. V Terminals
North America region version: (+NAR) (+NAR) NorthAmerica version
Input Cabling: (+CIT) (+CIT) Input Cabling Top
Output Cabling: (+COT) (+COT) Output Cabling Top
Brand: (+BM26) (+BM26) Vacon Dark Grey
Documentation Level: (+DPAP) (+DPAP) Paper manuals
Manual language: (+DDLUK) (+DDLUK) English Lang. Manuals
Firmware: (+F0000) (+F0000) No System firmware
Language package: (+FL00) (+FL00) No language package
Application: (+A0000) (+A0000)No Special Application
Supply frequency: (+LS50) (+LS50) 50Hz default settings
UL Approval: (+GNUL) (+GNUL) No UL Approval
CE Approval: (+GACE) (+GACE) CE Approval Mark
C-tick Approval: (+GNCT) (+GNCT) No RCM Approval
EAC Approval: (+GNEA) (+GNEA) No EAC approval
Ukrainian Approval: (+GNUA) (+GNUA) No Ukrainian Approval
Frame ID: (AF13) Frame 13 with AFE front end
Continuous Current (HO) [A]: 1030
Continuous Current (NO) [A]: 1180
Calculated Net Weight [kg]: 1950
Frame Size: AF13
