Watlow Circ Flg Std Tub Config.
Representative photo. Please check item description for details.

Watlow Circ Flg Std Tub Config.

https://www.branom.com/web/image/product.template/536044/image_1920?unique=c26756c
(0 review)

Circ Flange Voltage: 480
Circ Flange Wattage: 36,000
Watt Density: 23.0
B Dimension (Immersed element length): 47.8750
Number of Elements: 12 Elements
Electrical Phase configuration: 3 Phase - Delta wiring
Number of Circuits: 1
Flange Size: 6 Inch Flange
Flange Class: 150 lb.
Flange Material: Steel Flange
Sheath Material: Steel
Baffles? No Baffles
Cold End Section below the Flange: 4.5000
Process Sensor: No Process Sensor
Hi-Limit Sensor: No Hi-Limit Sensor
Thermowell required? Yes
Stand-off Terminal Enclosure? No
Terminal Enclosure: General Purpose (incl. CSA)
CE Low Volt Directive required? No
Use a Stainless Steel tank? No
Nameplate Part Number: CFPS747R5S
