213.40.2.5" 10000 psi 1/4 NPT lower mount Bourdon tube pressure gauge, liquid filled
Bourdon tube pressure gauge, liquid filled
forged brass case, model 213.40.0XX
Model: 213.40
Specifications according to data sheet: APM 213.40 (APM 02.06)
Measuring System: Copper Alloy
Movement: copper alloy
Nominal size: 2.5"
Unit of outer Scale: psi / -inHg
Measuring range: gauge pressure range
Scale range: 0/10000 psi
Process Connection: 1/4 NPT
Connector location: lower mount
Case: Forged Brass, Gold Painted
Bezel ring: Gold Plated ABS Ring
Window: acrylic (PMMA)
Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
Case filling: Glycerin
Type: 213.40
Dial description:
Pressure Gauge Standard: US-Standard
color for 1.scale (outside): black
dial background: White
Manufacturer logo: *WIKA®*
stop pin on dial: at zero
