- 2-wire loop-powered 4 mA to 20 mA output
- Linearized output to temperature
- Input RTD PT100 with 3-wire compensation
- Analog design, potentiometer adjustable
Applications:
Specifications
| Measurement Maximum | 200.0 |
| Min Operating Temperature | -40 °F |
| Product Unit of Measure | °F |
| Max Operating Temperature | 176 °F |
| Accuracy | 0.1% full scale |
| Case Material | Die-Cast Zinc, Enamel Painted |
| Power Supply | 12-32 VDC |
| Measurement Minimum | 0 |
| Input Communication Protocol | PT-100, 3-wire |
| Output Communication Protocol | 4-20 mA, 2-wire |
