Wika 232.53 Series 2.5" Stainless Steel Dry Pressure Gauge, 0 to 100 psi
Type 23X.5X, size 2.5" Stainless Steel, crimped
or removable bezel (53 or 54)
Model: 232.53.063
Specifications according to data sheet: 23X.53 and 23X.54 Nominal size: 2.5"
Measuring System: Stainless Steel Case: Non-removable crimp ring Scale range: 0/100 psi
2nd Scale / Special Scale: 2nd scale kPa Process Connection: 1/4 NPT Connector location: center back mount
Mounting Flange/Bracket: Panel mount with Stainless steel U-clamp Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
Material pressure element: Measuring System 316 SS Case filling fluid: prepared for filling
Window: Polycarbonate
Type 23X.5X, size 2.5" Stainless Steel, crimped
or removable bezel (53 or 54)
Model: 232.53.063
Specifications according to data sheet: 23X.53 and 23X.54 Nominal size: 2.5"
Measuring System: Stainless Steel Case: Non-removable crimp ring Scale range: 0/100 psi
2nd Scale / Special Scale: 2nd scale kPa Process Connection: 1/4 NPT Connector location: center back mount
Mounting Flange/Bracket: Panel mount with Stainless steel U-clamp Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
Material pressure element: Measuring System 316 SS Case filling fluid: prepared for filling
Window: Polycarbonate
Specifications
| Gauge: Brand | Wika |
| Gauge: Type | Dial Indicating Gauge |
