AVENTICS AP Series Directional Poppet Valve, Roller, G 1/4 Internal Thread, Aluminum, 3/2 Directional
Representative photo. Please check item description for details.

AVENTICS AP Series Directional Poppet Valve, Roller, G 1/4 Internal Thread, Aluminum, 3/2 Directional

https://www.branom.com/web/image/product.template/207532/image_1920?unique=c26756c
(0 review)

Series CH throttle valves can be used for nominal flows up to 4,100 l/min. The Series features special versions with integrated silencer and screw-in variants.

Features

  • Working pressure min.: 0 bar
  • Working pressure max: 16 bar
  • Min. ambient temperature: 0 °C
  • Max. ambient temperature: 100 °C
  • Min. medium temperature: 0 °C
  • Max. medium temperature: 100 °C
  • Port 1: G 1/4
  • Type: screw-in throttle
  • Medium: Compressed air
  • Compressed air connection type: External thread
  • Flow Qn: 750 l/min
  • Weight: 0.045 kg
  • Housing material: Brass:

$ 249.12 249.12 USD $ 249.12

$ 249.12

Not Available For Sale

    This combination does not exist.

    Contact Us
    Product Datasheets

    Datasheet 1
