Representative photo. Please check item description for details.

S4B Series Heavy Duty Type 4 Safety Light Curtain, Receiver (S4BR30-1200-S)

https://www.branom.com/web/image/product.template/543173/image_1920?unique=c26756c
(0 review)

Features:

  • SLC4 Type 4 Safety Light Curtain, Emitter
  • Resolution: 14 mm
  • Response (Tr): 11.5 ms
  • Range: 0.1 to 2 m (4 in to 6.5 ft)
  • Height: 320 mm (12.6 in)
  • Connection: 300 mm (1 ft) Pigtail
  • M12 4-pin QD
  • Mounting Hardware Ordered Separately
  • Min Operating Temperature: -20 °C
  • Max Operating Temperature: 55 °C
  • Ingress Protection: IP65
  • Housing Material_: Aluminum/Polycarbonate
  • Vibration: 10-55 Hz at 0.35 mm

$ 1,506.00 1506.0 USD $ 1,506.00

$ 1,506.00

Not Available For Sale

    This combination does not exist.

    Contact Us

    Share

    Features:

    • SLC4 Type 4 Safety Light Curtain, Emitter
    • Resolution: 14 mm
    • Response (Tr): 11.5 ms
    • Range: 0.1 to 2 m (4 in to 6.5 ft)
    • Height: 320 mm (12.6 in)
    • Connection: 300 mm (1 ft) Pigtail
    • M12 4-pin QD
    • Mounting Hardware Ordered Separately
    • Min Operating Temperature: -20 °C
    • Max Operating Temperature: 55 °C
    • Ingress Protection: IP65
    • Housing Material_: Aluminum/Polycarbonate
    • Vibration: 10-55 Hz at 0.35 mm
