  3. World-Beam Q20 Series: Emitter (Red) (Q20E W/17)
Public Pricelist (v2)
World-Beam Q20 Series: Emitter (Red) (Q20E W/17)
Representative photo. Please check item description for details.

World-Beam Q20 Series: Emitter (Red) (Q20E W/17)

https://www.branom.com/web/image/product.template/204078/image_1920?unique=c26756c
(0 review)

Features:

    WORLD-BEAM Q20 Series: Emitter (Red); Range: 12 m; Input 10-30V dc; Output: No output; 5 m (17 ft) Cable
    • Min Operating Temperature: -20 °C
  • Max Operating Temperature: 60 °C
  • Lens Material: Acrylic
  • Power Supply: 10-30 VDC
  • Delay at Power-Up: 100 ms
  • Ingress Protection: IP67
  • Repeatability (µs): 140
  • Sensing Beam: Visible Red LED
  • Sensing Beam Wavelength: 655
  • Housing Style: Rectangular
  • Max Sensing Distance: 12000 mm
  • Sensing Mode (Detailed): Emitter
  • Sensing Mode (General): Opposed
  • Max Relative Humidity: 95% @ 50 °C
  • Housing Material_: Thermoplastic
  • Feature: Hazardous Area: No
  • DeviceNet: No
  • Feature: IO Link: No
  • Feature: Quick Disconnect: No
  • Feature: Audible: No
  • Feature: Chemical Resistant: No
  • Opposed Mode Emitter/Receiver: Emitter
  • Feature: Water Detection: No
  • Number of Pins: 4
  • Adjustments: N/A
  • Feature: Timing (Hold/Delay): No
  • Feature: Encapsulated: No
  • Feature: Remote Teach: No
  • Feature: Intrinsically Safe: No
  • Connection Type: Cable
  • NEMA / UL: NEMA 6
  • Cord/Cable Length: 5 m
  • Indicator Type: LED

$ 78.00 78.0 USD $ 78.00

$ 78.00

Not Available For Sale

    This combination does not exist.

    Contact Us
    Product Datasheets

    Datasheet 1
