Wika 233.54 Series Glycerin Filled Pressure Gauge, 4" Dial, -1 to 15 bar, 1/4 NPT SS Lower Mount, Rear Flange
The Wika 233.54 Series Stainless Steel Pressure Gauge is designed for the most demanding industrial applications, where pulsation and vibration are prevalent. This robust gauge is perfectly suited for the process industry, including chemical and petrochemical sectors, power stations, mining operations, both onshore and offshore projects, environmental technology, mechanical engineering, and plant construction. It is ideal for use with gaseous or liquid media that do not obstruct the pressure system.
Featuring an all stainless steel construction, the Series 233.54 guarantees maximum durability and corrosion resistance, making it reliable even in the harshest environments. The liquid-filled case enhances its vibration and shock resistance, ensuring accurate readings under adverse service conditions. A notable feature is the NEW FlexWindow option available on 2-1/2” gauges, which improves readability and durability. This gauge supports pressure ranges up to 15,000 psi (1,000 bar), making it versatile for various high-pressure applications.
When it comes to purchasing the Wika 233.54 Series Stainless Steel Pressure Gauge, Branom stands out as the best store. Known for exceptional customer care, Branom ensures that you receive the expert advice and support needed to find the perfect gauge for your specific needs. With Branom, you can trust that you are getting the highest quality products backed by outstanding service.
Features
- Type 23X.5X, size 4" Stainless Steel, crimped or removable bezel (53 or 54)
- Specifications according to data sheet: 23X.53 and 23X.54
- Measuring System: Stainless Steel
- Case: Non-removable crimp ring
- Scale range: -1/15 bar
- Process Connection: 1/4 NPT
- Connector location: lower mount
- Mounting Flange/Bracket: Rear Flange, Stainless Steel
- Accuracy Class: +/- 1% (ASME B40.100 Grade 1A)
- Material pressure element: Measuring System 316L
- Case filling fluid: Glycerine
- Window: Polycarbonate
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
- QR code with extended serial number on dial
The Wika 233.54 Series Stainless Steel Pressure Gauge is designed for the most demanding industrial applications, where pulsation and vibration are prevalent. This robust gauge is perfectly suited for the process industry, including chemical and petrochemical sectors, power stations, mining operations, both onshore and offshore projects, environmental technology, mechanical engineering, and plant construction. It is ideal for use with gaseous or liquid media that do not obstruct the pressure system.
Featuring an all stainless steel construction, the Series 233.54 guarantees maximum durability and corrosion resistance, making it reliable even in the harshest environments. The liquid-filled case enhances its vibration and shock resistance, ensuring accurate readings under adverse service conditions. A notable feature is the NEW FlexWindow option available on 2-1/2” gauges, which improves readability and durability. This gauge supports pressure ranges up to 15,000 psi (1,000 bar), making it versatile for various high-pressure applications.
When it comes to purchasing the Wika 233.54 Series Stainless Steel Pressure Gauge, Branom stands out as the best store. Known for exceptional customer care, Branom ensures that you receive the expert advice and support needed to find the perfect gauge for your specific needs. With Branom, you can trust that you are getting the highest quality products backed by outstanding service.
Features
- Type 23X.5X, size 4" Stainless Steel, crimped or removable bezel (53 or 54)
- Specifications according to data sheet: 23X.53 and 23X.54
- Measuring System: Stainless Steel
- Case: Non-removable crimp ring
- Scale range: -1/15 bar
- Process Connection: 1/4 NPT
- Connector location: lower mount
- Mounting Flange/Bracket: Rear Flange, Stainless Steel
- Accuracy Class: +/- 1% (ASME B40.100 Grade 1A)
- Material pressure element: Measuring System 316L
- Case filling fluid: Glycerine
- Window: Polycarbonate
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
- QR code with extended serial number on dial
Specifications
| Gauge: Brand | Wika |
| Gauge: Product Unit of Measure | bar |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Process Connection Type | Rear Flange |
| Gauge: Case Material | Stainless Steel |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Dial Size | 4 in (100 mm) |
| Gauge: Process Connection Size | 1/4 NPT |
| Gauge: Accuracy | ±1% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 233.54 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Type | Dial Indicating Gauge |
