Turck FOUNDATION fieldbus and PROFIBUS-PA, IP66 junction box, 4-channel (JBBS-49SC-T435)

https://www.branom.com/web/image/product.template/167965/image_1920?unique=c26756c
(0 review)
FOUNDATION fieldbus and PROFIBUS-PA Features
  • IP66 junction box
  • 4-channel
  • Junction box for wall mounting with PVC cable glands M20 x 1.5
  • Short-circuit protection per drop line/spur
  • Integrated terminating resistor (activatable)
  • Cable shielding: Capacitive or direct connection to housing potential selectable via switch
  • Isolated support terminal for optional protective conductor incorporated in cable
  • Stainless steel housing
  • Pressure compensation element protects against condensation
  • Connection of the housing potential via M5 x 1 bolt

$ 962.60 962.6 USD $ 962.60

$ 962.60

Not Available For Sale

  • Measurement Maximum
  • Case Material
  • Measurement Minimum
  • Country of Origin

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

FOUNDATION fieldbus and PROFIBUS-PA Features

  • IP66 junction box
  • 4-channel
  • Junction box for wall mounting with PVC cable glands M20 x 1.5
  • Short-circuit protection per drop line/spur
  • Integrated terminating resistor (activatable)
  • Cable shielding: Capacitive or direct connection to housing potential selectable via switch
  • Isolated support terminal for optional protective conductor incorporated in cable
  • Stainless steel housing
  • Pressure compensation element protects against condensation
  • Connection of the housing potential via M5 x 1 bolt

Specifications

Measurement Maximum 0
Case Material 304 SS
Measurement Minimum 0
Country of Origin DE
