Plastic Fiber, Convergent (PLI-A10)

https://www.branom.com/web/image/product.template/34427/image_1920?unique=c26756c
(0 review)

Features:

  • Plastic Fiber, Convergent
  • Core Dia.: 0.5 mm & 9 x 0.25 mm
  • Fiber Length 2 m
  • Lens
  • Free cut
  • Max Operating Temperature: 70 °C
  • Housing Style: Round
  • Sensing Mode (Detailed): Coaxial
  • Sensing Mode (General): Diffuse
  • Feature: Chemical Resistant: No
  • Sensing End Segment 1: Ferrule
  • Tariff Fiber Meters: 20 fbm
  • Min Bend Radius: 5 mm
  • Feature: Vacuum Feed Through: None
  • Feature: Small Object Detection: Yes
  • Fiber Sensing End Size: M6
  • Feature: Retractile: No
  • Fiber Sensing End Tip: Lens
  • Termination: Free Cut
  • Sensing End Material (Specific): Aluminum
  • Feature: Integrated Lens: No
  • Core Diameter: 0.5 & 9 x 0.3 mm
  • Fiber Sheathing Material (Jacket): Polyethylene
  • Feature: Extended Range: No
  • Feature: Flex Relief: No
  • Termination Type: Plastic Fiber Sensors
  • Fiber Sensing End Size - Mounting Area: M6
  • Fiber Length: 2 m
  • Fiber Optic Type: Plastic
  • Sensing End Segment 2: Thread
  • Sensing End Segment 3: Lens
  • Beam Exit: In-line
  • Feature: Liquid Level: No
  • Min Hinged Door Size: 5 mm
  • Min Repeat Bending Endurance: 1000
  • Max Distance: DF-G1: No Data
  • Max Distance: DF-G3: No Data
  • Max Distance: DF-G2: No Data
  • Minimum Bend Radius: 5 mm

$ 200.00 200.0 USD $ 200.00

$ 200.00

Not Available For Sale

    This combination does not exist.

    Contact Us

    Share
