Representative photo. Please check item description for details.

Turck BL20 Economy Module, 8 2-wire Analog Inputs U/I resp. 4 2/3-wire PT/NI Inputs (BL20-E-8AI-U/I-4PT/NI)

https://www.branom.com/web/image/product.template/166107/image_1920?unique=c26756c
(0 review)
BL20 Economy Module Features
  • 8 2-wire Analog Inputs U/I resp. 4 2/3-wire PT/NI Inputs
  • Fieldbus-independent
  • Electronics and connection technology in one housing
  • Connectivity: Push-in terminals
  • Protection class IP20
  • LEDs indicate status and diagnostic
  • Electronics galvanically separated from the field level via optocouplers
  • 8 analog 2-wire inputs U/I
  • Passive input - External supply
  • 0 … 20 mA
  • 4 … 20 mA
  • -10 … +10 VDC or 0 … +10 VDC
  • selectable per channel
  • Alternatively: 4PT/NI inputs (always 2 analog inputs are combined to a PT/Ni 2/3-wire input)

$ 558.86 558.86 USD $ 558.86

$ 558.86

Not Available For Sale

  • Measurement Minimum
  • Country of Origin

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

BL20 Economy Module Features

  • 8 2-wire Analog Inputs U/I resp. 4 2/3-wire PT/NI Inputs
  • Fieldbus-independent
  • Electronics and connection technology in one housing
  • Connectivity: Push-in terminals
  • Protection class IP20
  • LEDs indicate status and diagnostic
  • Electronics galvanically separated from the field level via optocouplers
  • 8 analog 2-wire inputs U/I
  • Passive input - External supply
  • 0 … 20 mA
  • 4 … 20 mA
  • -10 … +10 VDC or 0 … +10 VDC
  • selectable per channel
  • Alternatively: 4PT/NI inputs (always 2 analog inputs are combined to a PT/Ni 2/3-wire input)

Specifications

Measurement Minimum 0
Country of Origin DE
