Turck Compact Multiprotocol I/O Module for Ethernet, 2 Configurable Serial Interfaces and 4 Universal Digital Channels (TBEN-S2-2COM-4DXP)

https://www.branom.com/web/image/product.template/172048/image_1920?unique=c26756c
(0 review)
Compact Multiprotocol I/O Module for Ethernet Features
  • 2 Configurable Serial Interfaces and 4 Universal Digital Channels
  • PROFINET device
  • EtherNet/IP device or Modbus TCP slave
  • Integrated Ethernet switch
  • Supports 10 Mbps / 100 Mbps
  • 2x M8
  • 4-pin
  • Ethernet fieldbus connection
  • Glass fiber reinforced housing
  • Shock and vibration tested
  • Fully potted module electronics
  • Protection classes IP65
  • IP67
  • IP69K
  • 4-pin M8 male connector for power supply
  • Galvanically isolated voltage groups
  • ATEX Zone 2/22
  • Input diagnostics per group
  • Max. 0.5A per output
  • Output diagnostics per channel
  • Two freely selectable digital channels per port
  • Two serial ports can be selected as RS485 or RS232
  • Up to eight Modbus RTU slaves integrated per serial interface
  • Four freely selectable digital channels as input or output
  • Programmable ARGEE

$ 877.70 877.7 USD $ 877.70

$ 877.70

Not Available For Sale

  • Measurement Maximum
  • Measurement Minimum
  • Country of Origin

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

Compact Multiprotocol I/O Module for Ethernet Features

  • 2 Configurable Serial Interfaces and 4 Universal Digital Channels
  • PROFINET device
  • EtherNet/IP device or Modbus TCP slave
  • Integrated Ethernet switch
  • Supports 10 Mbps / 100 Mbps
  • 2x M8
  • 4-pin
  • Ethernet fieldbus connection
  • Glass fiber reinforced housing
  • Shock and vibration tested
  • Fully potted module electronics
  • Protection classes IP65
  • IP67
  • IP69K
  • 4-pin M8 male connector for power supply
  • Galvanically isolated voltage groups
  • ATEX Zone 2/22
  • Input diagnostics per group
  • Max. 0.5A per output
  • Output diagnostics per channel
  • Two freely selectable digital channels per port
  • Two serial ports can be selected as RS485 or RS232
  • Up to eight Modbus RTU slaves integrated per serial interface
  • Four freely selectable digital channels as input or output
  • Programmable ARGEE

Specifications

Measurement Maximum 0
Measurement Minimum 0
Country of Origin DE
