Turck FOUNDATION fieldbus, IP67 junction box, 6-channel (JBBS-49SC-T614/3G)
FOUNDATION fieldbus Features
- IP67 junction box
- 6-channel
- Junction box for wall mounting with nickel-plated brass cable glands M20 x 1.5
- Short-circuit protection per drop line/spur
- Integrated terminating resistor (activatable)
- Cable shielding: Capacitive or direct connection to housing potential selectable via switch
- Isolated support terminal for optional protective conductor incorporated in cable
- Powder-coated die-cast aluminium housing
- Pressure compensation element protects against condensation
- Connection of the housing potential via M5 x 1 bolt
- Entity and FISCO compliant according to IEC 60079-11
FOUNDATION fieldbus Features
- IP67 junction box
- 6-channel
- Junction box for wall mounting with nickel-plated brass cable glands M20 x 1.5
- Short-circuit protection per drop line/spur
- Integrated terminating resistor (activatable)
- Cable shielding: Capacitive or direct connection to housing potential selectable via switch
- Isolated support terminal for optional protective conductor incorporated in cable
- Powder-coated die-cast aluminium housing
- Pressure compensation element protects against condensation
- Connection of the housing potential via M5 x 1 bolt
- Entity and FISCO compliant according to IEC 60079-11
Specifications
| Measurement Maximum | 0 |
| Case Material | Powder-Coated Auminum |
| Measurement Minimum | 0 |
| Country of Origin | DE |
