Representative photo. Please check item description for details.
Wika PXS4ME Mini Pressure Switch, 1.6 - 6 Bar Range, 1/4" NPT Internal Female - 1/2"-14 NPT External Male Process Threads, 5M Cable
Features:
- Mini pressure switch
- Stainless steel switch enclosure
- Model PXS
- Specifications according to data sheet: PV 34.36
- Repeatability of set point: ≤ 1% of end of setting range
- measuring element: diaphragm with antagonist spring, Hastelloy C276, welded or with O-ring (1…2,5 to 6…25 bar)
- contacts: 1xSPDT, silver contact, hermetically sealed
- measuring range, working range, proof pressure: 1,6 … 6 bar, working range 0 … 10 bar, proof pressure 16 bar
- Setting range depending on the switching direction: increasing 2,1…6 bar; decreasing 1,6...5,8 bar
- Set Point customer-specifically configured
- process connection: 1/4 NPT-F
- electrical connection: 1/2-14 NPT-M, with 5m cable
- Mounting: direct mounting
- brand: WIKA Instruments Italia
- Ingress Protection: IP66
- Connection: Stainless steel AISI 316L
- PXS4ME
- Approvals / Certificates
- IECEx-ATEX Ex ia
- 1. set point: 4.15 bar decreasing
