Representative photo. Please check item description for details.
Wika 232.53 Series 2" SS Dry Pressure Gauge, 0 to 60 psi, 2nd Scale bar, 1/4 NPT, LM
This high-quality Bourdon tube pressure gauge has been designed especially for the process industry.
The use of high-quality stainless steel materials and the robust design are geared to applications in the chemical and process engineering industries. Thus the instrument is suitable for liquid and gaseous media, also in aggressive environments.
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Details
Pressure Gauge, size 2.0" Stainless Steel, crimpedbezel
Measuring System: Stainless Steel
Case: Non-removable crimp ring
Scale range: 0/60 psi
2nd Scale / Special Scale: 2nd scale bar
Process Connection: 1/4 NPT
Connector location: lower mount
Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
Material pressure element: Measuring System 316 SS
Window: Polycarbonate
Dial description:
Pressure Gauge Standard: US-Standard
color for 1.scale (outside): black
color for 2.scale (inside): red
dial background: White
*WIKA®*
serial number on dial: Serial number *...*
stop pin on dial: at zero
This high-quality Bourdon tube pressure gauge has been designed especially for the process industry.
The use of high-quality stainless steel materials and the robust design are geared to applications in the chemical and process engineering industries. Thus the instrument is suitable for liquid and gaseous media, also in aggressive environments.
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Details
Pressure Gauge, size 2.0" Stainless Steel, crimpedbezel
Measuring System: Stainless Steel
Case: Non-removable crimp ring
Scale range: 0/60 psi
2nd Scale / Special Scale: 2nd scale bar
Process Connection: 1/4 NPT
Connector location: lower mount
Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
Material pressure element: Measuring System 316 SS
Window: Polycarbonate
Dial description:
Pressure Gauge Standard: US-Standard
color for 1.scale (outside): black
color for 2.scale (inside): red
dial background: White
*WIKA®*
serial number on dial: Serial number *...*
stop pin on dial: at zero
Specifications
| Gauge: Brand | Wika |
| Gauge: Product Unit of Measure | psi |
| Gauge: 2nd Scale | bar |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Ingress Protection | IP 54 |
| Gauge: Case Material | Stainless Steel |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Fill Type | Dry |
| Gauge: Dial Size | 2 in (50 mm) |
| Gauge: Process Connection Size | 1/2 NPT |
| Gauge: Accuracy | ±2% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 232.53 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Type | Dial Indicating Gauge |
