Representative photo. Please check item description for details.
Wika 233.54 Series 4" SS Pressure Gauge, -30 inHg to 200 psi, 2nd Scale bar, G 1/4 B, LM, Ready to Fill
This high-quality Bourdon tube pressure gauge has been designed especially for the process industry.
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Features
- Type 23X.5X, size 4" Stainless Steel, crimped or removable bezel (53 or 54)
- Specifications according to data sheet: 23X.53 and 23X.54
- Measuring System: Stainless Steel
- Case: Removable bayonet ring
- Scale range: -30 inHg/200 psi
- 2nd Scale / Special Scale: 2nd scale bar
- Process Connection: G 1/4 B
- Connector location: lower mount
- Accuracy Class: +/- 1% (ASME B40.100 Grade 1A)
- Material pressure element: Measuring System 316L
- Case filling fluid: prepared for filling
- Pointer: adjustable pointer
- Window: laminated safety glass
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- color for 2.scale (inside): red
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
This high-quality Bourdon tube pressure gauge has been designed especially for the process industry.
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Features
- Type 23X.5X, size 4" Stainless Steel, crimped or removable bezel (53 or 54)
- Specifications according to data sheet: 23X.53 and 23X.54
- Measuring System: Stainless Steel
- Case: Removable bayonet ring
- Scale range: -30 inHg/200 psi
- 2nd Scale / Special Scale: 2nd scale bar
- Process Connection: G 1/4 B
- Connector location: lower mount
- Accuracy Class: +/- 1% (ASME B40.100 Grade 1A)
- Material pressure element: Measuring System 316L
- Case filling fluid: prepared for filling
- Pointer: adjustable pointer
- Window: laminated safety glass
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- color for 2.scale (inside): red
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
Specifications
| Gauge: Brand | Wika |
| Gauge: Product Unit of Measure | psi / inHg |
| Gauge: 2nd Scale | bar |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Case Material | Stainless Steel |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Dial Size | 4 in (100 mm) |
| Gauge: Process Connection Size | G 1/4 B |
| Gauge: Accuracy | ±1% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 232.54 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Type | Dial Indicating Gauge |
