Wika 233.50 Series 4.5" SS Pressure Gauge, 0 to 15 psi, 1/2 NPT, LM, Glycerin Filled
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Special Features
- Excellent load-cycle stability and shock resistance
- With case filling (model 233.50) for applications with high dynamic pressure loads and vibrations
- Completely from stainless steel
- Scale ranges from 0 … 0.6 to 0 … 1,600 bar [0 ... 10 to 0 ... 20,000 psi]
Features
- Bourdon Tube Pressure Gauges, 4.5" Stainles Steel
- Series, standard case with blow-out plug (50) or
- solid front safety case (30)
- Nominal size: 4.5"
- Measuring System: Stainless Steel
- Case: With Pressure Blowout Disk
- Scale range: 0/15 psi
- Process Connection: 1/2 NPT
- Connector location: lower mount
- Accuracy Class: +/- .5% (ASME B40.100 2A)
- Case surface: bare
- Material pressure element: Measuring System 316L
- Case filling fluid: Glycerine
- Window: laminated safety glass
- Ingress Protection: IP 65
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Special Features
- Excellent load-cycle stability and shock resistance
- With case filling (model 233.50) for applications with high dynamic pressure loads and vibrations
- Completely from stainless steel
- Scale ranges from 0 … 0.6 to 0 … 1,600 bar [0 ... 10 to 0 ... 20,000 psi]
Features
- Bourdon Tube Pressure Gauges, 4.5" Stainles Steel
- Series, standard case with blow-out plug (50) or
- solid front safety case (30)
- Nominal size: 4.5"
- Measuring System: Stainless Steel
- Case: With Pressure Blowout Disk
- Scale range: 0/15 psi
- Process Connection: 1/2 NPT
- Connector location: lower mount
- Accuracy Class: +/- .5% (ASME B40.100 2A)
- Case surface: bare
- Material pressure element: Measuring System 316L
- Case filling fluid: Glycerine
- Window: laminated safety glass
- Ingress Protection: IP 65
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
Specifications
| Gauge: Brand | Wika |
| Gauge: Product Unit of Measure | psi |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Ingress Protection | IP 65 |
| Gauge: Case Material | Stainless Steel |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Dial Size | 4-1/2 in (110 & 115 mm) |
| Gauge: Process Connection Size | 1/2 NPT |
| Gauge: Accuracy | ±0.5% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 233.50 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Type | Dial Indicating Gauge |
