400Mm Conn Assy Molex 39-01-2040/39-00-0046 (SM31EL-52295)
Representative photo. Please check item description for details.

400Mm Conn Assy Molex 39-01-2040/39-00-0046 (SM31EL-52295)

https://www.branom.com/web/image/product.template/203865/image_1920?unique=c26756c
(0 review)

Features:

    SM31EL-52295 400MM CONN ASSY MOLEX 39-01-2040/39-00-0046
  • Lens Material: Acrylic
  • Power Supply: 10-30 VDC
  • Delay at Power-Up: 100 ms
  • Ingress Protection: IP67
  • Repeatability (µs): 140
  • Sensing Beam: Infrared LED
  • Housing Style: Rectangular w/M18 Mount
  • Max Sensing Distance: 30000 mm
  • Sensing Mode (Detailed): Emitter
  • Sensing Mode (General): Opposed
  • Feature: Hazardous Area: No
  • DeviceNet: No
  • Feature: IO Link: No
  • Feature: Quick Disconnect: No
  • Feature: Audible: No
  • Quick Disconnect Type: Molex
  • Feature: Chemical Resistant: No
  • Opposed Mode Emitter/Receiver: Emitter
  • Feature: Water Detection: No
  • Number of Pins: 4
  • Output Response Time: 1 ms
  • Adjustments: Potentiometer
  • Feature: Timing (Hold/Delay): No
  • Feature: Encapsulated: No
  • Barrel Diameter: 18
  • Feature: Remote Teach: No
  • Feature: Intrinsically Safe: No
  • Connection: Pigtail QD
  • NEMA / UL: NEMA 1/2/3/3S/4/4X/6/12
  • Cord/Cable Length: 400 mm
  • Indicator Type: LED

$ 107.00 107.0 USD $ 107.00

$ 107.00

Not Available For Sale

    This combination does not exist.

    Contact Us
    Product Datasheets

    Datasheet 1
