Representative photo. Please check item description for details.
Wika 233.34 Series 4.5" SS Process Gauge, 0 to 100 psig, 1/2 NPT, LM, Glycerin Filled
Applications
- For applications with high dynamic pressure pulsations or vibration a liquid filled case and socket restrictor are available
- Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
- Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Product Features
- Excellent load-cycle stability and shock resistance
- Solid front thermoplastic case
- Positive pressure ranges to 30,000 psi (2,000 bar)
- All lower mount connection gauges are factory prepared for case filling
Features
- Process Gauge
- Model: 233.34
- Specifications according to data sheet: APM 02.10
- Case: Black Fiberglass Reinforced Thermoplastic (Pocan B4225)
- Bezel ring: Threaded, Black Fiberglass Reinforced Thermoplastic (Pocan B4225)
- Measuring System: Stainless Steel
- Case filling: with
- Nominal size: 4.5"
- Scale range: 0/100 psig
- Process Connection: 1/2 NPT
- Connector location: lower mount
- Window: laminated safety glass
- Restrictor: stainless steel, D 0.6
- Pointer: adjustable pointer
- Accuracy Class: +/- .5% (ASME B40.100 2A)
- Material pressure element: Measuring System 316L
- Case filling fluid: Glycerine
- Ingress Protection: IP 65
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
- stop pin on dial: at 6 o'clock
Applications
- For applications with high dynamic pressure pulsations or vibration a liquid filled case and socket restrictor are available
- Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
- Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Product Features
- Excellent load-cycle stability and shock resistance
- Solid front thermoplastic case
- Positive pressure ranges to 30,000 psi (2,000 bar)
- All lower mount connection gauges are factory prepared for case filling
Features
- Process Gauge
- Model: 233.34
- Specifications according to data sheet: APM 02.10
- Case: Black Fiberglass Reinforced Thermoplastic (Pocan B4225)
- Bezel ring: Threaded, Black Fiberglass Reinforced Thermoplastic (Pocan B4225)
- Measuring System: Stainless Steel
- Case filling: with
- Nominal size: 4.5"
- Scale range: 0/100 psig
- Process Connection: 1/2 NPT
- Connector location: lower mount
- Window: laminated safety glass
- Restrictor: stainless steel, D 0.6
- Pointer: adjustable pointer
- Accuracy Class: +/- .5% (ASME B40.100 2A)
- Material pressure element: Measuring System 316L
- Case filling fluid: Glycerine
- Ingress Protection: IP 65
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- dial background: White
- *WIKA®*
- serial number on dial: Serial number *...*
- stop pin on dial: at 6 o'clock
Specifications
| Gauge: Brand | Wika |
| Gauge: Product Unit of Measure | psig |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Ingress Protection | IP 65 |
| Gauge: Case Material | Plastic |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Dial Size | 4-1/2 in (110 & 115 mm) |
| Gauge: Process Connection Size | 1/2 NPT |
| Gauge: Accuracy | ±0.5% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 233.34 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Type | Dial Indicating Gauge |
