Turck Inductive Sensor, With Extended Switching Distance (NI4U-Q8SE-AP6X-0.2-PSG3)
Representative photo. Please check item description for details.

Turck Inductive Sensor, With Extended Switching Distance (NI4U-Q8SE-AP6X-0.2-PSG3)

https://www.branom.com/web/image/product.template/169720/image_1920?unique=c26756c
(0 review)
Inductive Sensor Features
  • With Extended Switching Distance
  • Rated switching distance 4 mm
  • Cable length (L) 0.2 m
  • Non-flush
  • Rectangular
  • height 8 mm
  • Active face on top
  • Metal
  • GD-ZnAI
  • Factor 1 for all metals
  • Increased switching distance
  • Protection class IP68
  • Resistant to magnetic fields
  • Auto-compensation protects against pre-damping
  • Flush mounted installation on up to 4 sides
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • PNP output
  • Pigtail with male end M8 x 1

$ 141.30 141.3 USD $ 141.30

$ 141.30

Not Available For Sale

  • Measurement Maximum
  • Case Material
  • Measurement Minimum
  • Output Communication Protocol
  • Input Voltage

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

Inductive Sensor Features

  • With Extended Switching Distance
  • Rated switching distance 4 mm
  • Cable length (L) 0.2 m
  • Non-flush
  • Rectangular
  • height 8 mm
  • Active face on top
  • Metal
  • GD-ZnAI
  • Factor 1 for all metals
  • Increased switching distance
  • Protection class IP68
  • Resistant to magnetic fields
  • Auto-compensation protects against pre-damping
  • Flush mounted installation on up to 4 sides
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • PNP output
  • Pigtail with male end M8 x 1

Specifications

Measurement Maximum 0
Case Material Plastic
Measurement Minimum 0
Output Communication Protocol PNP
Input Voltage 10-30 VDC
