Custom Circulation Htr 3" 150# Flg

Circ Flange Size: 3 Inch
Circ Flange Class: 150 lb.
Flange/Vessel Material: Steel Flange
Inlet/Outlet Nozzle Size: 1 inch
Nozzle Connection: Male NPT
Cold End (below flange): 3.8750
Inlet Configuration: U Configuration, Inlet nozzle near flange
Orientation: Horizontal
Mounting: Blocks
Process Sensor (Outlet Nozzle): None
Gasket: 700 degree F, Compressed Fiber
Insulation Material: Fiberglass
Shroud Material: Aluminum
Flange Voltage: 240
Flange Wattage: 6,000
Watt Density: 10.0
B Dimension (Immersed element length calculated): 40.8750
Number of Elements: 6 Elements
Electrical Phase configuration: 1 Phase - Parallel wiring
Number of Circuits: 1
Flange Size: 3 Inch Flange
Flange Class: 150 lb.
Flange Material: Steel Flange
Sheath Material: Alloy 800
Baffles? No Baffles
Cold End Section below the Flange: 3.8750
Passivate wetted parts? No
Process Sensor: No Process Sensor
Hi-Limit Sensor: Type K Thermocouple
Thermowell required? No
Mounting Orientation: Horizontal
Number of Hilimit Sensors (1 or 2): 1
First Hi-Limit Location: 27.2500
Stand-off Terminal Enclosure? No
Terminal Enclosure: Moisture Resistant (standard)
CE Low Volt Directive required? No
Nameplate Part Number: 2343-8783 FL6
Flange part number: 2343-8783
