Vision Light: 70 mm Ring (LEDUV395R70XD5-XQ)
Representative photo. Please check item description for details.

Vision Light: 70 mm Ring (LEDUV395R70XD5-XQ)

https://www.branom.com/web/image/product.template/6790/image_1920?unique=c26756c
(0 review)

Features:

  • Vision Light: 70 mm Ring
  • 4 High Intensity 395nm UV LEDs
  • 24 V dc
  • Clear Diffusing Plastic Window
  • Requires Cable MQDC20-xxx
    • Power: DC
  • Max Current Color: 350 mA
  • Max Operating Temperature: 50 °C
  • Housing Style: Rectangular
  • Device Type: Ring Light
  • Housing Material_: Anodized Aluminum
  • Physical Dimensions: 76.2 x 76.2 x 63.0 mm
  • Supply Voltage: 24 V DC
  • Feature: Quick Disconnect: Yes
  • Color Technology: Standard LED
  • Quick Disconnect Type: M12
  • Number of Input Pins/Conductors: 5
  • Color: Ultraviolet
  • QD Type/Cable Length: M12; requires mating cordset
  • Connection Type: Integral QD

$ 864.00 864.0 USD $ 864.00

$ 864.00

Not Available For Sale

    This combination does not exist.

    Contact Us

    Share

    Features:

    • Vision Light: 70 mm Ring
    • 4 High Intensity 395nm UV LEDs
    • 24 V dc
    • Clear Diffusing Plastic Window
    • Requires Cable MQDC20-xxx
      • Power: DC
    • Max Current Color: 350 mA
    • Max Operating Temperature: 50 °C
    • Housing Style: Rectangular
    • Device Type: Ring Light
    • Housing Material_: Anodized Aluminum
    • Physical Dimensions: 76.2 x 76.2 x 63.0 mm
    • Supply Voltage: 24 V DC
    • Feature: Quick Disconnect: Yes
    • Color Technology: Standard LED
    • Quick Disconnect Type: M12
    • Number of Input Pins/Conductors: 5
    • Color: Ultraviolet
    • QD Type/Cable Length: M12; requires mating cordset
    • Connection Type: Integral QD
