Turck Inductive Sensor, Monitoring Kit for Power Clamps (NI2-GEN-BDS-2AP6X3-H1141/S34)
Inductive Sensor Features
- Monitoring Kit for Power Clamps
- Rated switching distance 2 mm
- Non-flush
- BDS power block with two integrated sensors and LEDs
- Robust rotatable connector 0°
- 45° and 90°
- for optimal cable routing
- Plastic
- Trogamid
- Resistant to magnetic fields (weld-resistant)
- for DC and AC fields up to 100 mT
- 2 x NO contact
- PNP output
- DC 4-wire
- 10…30 VDC
Inductive Sensor Features
- Monitoring Kit for Power Clamps
- Rated switching distance 2 mm
- Non-flush
- BDS power block with two integrated sensors and LEDs
- Robust rotatable connector 0°
- 45° and 90°
- for optimal cable routing
- Plastic
- Trogamid
- Resistant to magnetic fields (weld-resistant)
- for DC and AC fields up to 100 mT
- 2 x NO contact
- PNP output
- DC 4-wire
- 10…30 VDC
Specifications
| Measurement Maximum | 0 |
| Case Material | Metal |
| Measurement Minimum | 0 |
| Output Communication Protocol | PNP |
| Input Voltage | 10-30 VDC |
| Country of Origin | DE |
