Turck Inductive Sensor, Monitoring Kit for Power Clamps (NI2-Q6.5-AN6-0.1-FS4.4X3/S304)

https://www.branom.com/web/image/product.template/169380/image_1920?unique=c26756c
(0 review)
Inductive Sensor Features
  • Monitoring Kit for Power Clamps
  • Rated switching distance 2 mm
  • Cable length (L) 0.1 m
  • Non-flush
  • Q6
  • 5 power block with two connected sensors and LEDs
  • Relocatable block 0°…90°
  • with cross drilling for flexible cable routing
  • Plastic
  • PBT‐GF20‐V0
  • Resistant to magnetic fields (weld-resistant)
  • for DC and AC fields up to 100 mT
  • 2 x NO contact
  • NPN output
  • DC 4-wire
  • 10…30 VDC

$ 267.40 267.4 USD $ 267.40

$ 267.40

Not Available For Sale

  • Measurement Maximum
  • Case Material
  • Measurement Minimum
  • Output Communication Protocol
  • Input Voltage
  • Country of Origin

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

Inductive Sensor Features

  • Monitoring Kit for Power Clamps
  • Rated switching distance 2 mm
  • Cable length (L) 0.1 m
  • Non-flush
  • Q6
  • 5 power block with two connected sensors and LEDs
  • Relocatable block 0°…90°
  • with cross drilling for flexible cable routing
  • Plastic
  • PBT‐GF20‐V0
  • Resistant to magnetic fields (weld-resistant)
  • for DC and AC fields up to 100 mT
  • 2 x NO contact
  • NPN output
  • DC 4-wire
  • 10…30 VDC

Specifications

Measurement Maximum 0
Case Material Metal
Measurement Minimum 0
Output Communication Protocol NPN
Input Voltage 10-30 VDC
Country of Origin DE
