Turck Ultrasonic Sensor, Diffuse Mode Sensor (RU40U-EM18E-LIU2PN8X2T-H1151/3GD)

Ultrasonic Sensor Features

Diffuse Mode Sensor
Max. range 400 mm
Smooth sonic transducer face
Cylindrical housing M18
potted
Connection via M12 x 1 male
Teach range adjustable via pushbutton or adapter
Temperature compensation
Blind zone: 2.5 cm
Range: 40 cm
Resolution: 0.5 mm
Aperture angle of sonic cone: ±15 °
1 × switching output
PNP/NPN
1 × analog output
4…20 mA / 0…10 V / additional switching output
PNP/NPN
NO/NC programmable
Transmission of process value and parametrization via IO-link
ATEX II 3 G approval
Gases and vapors
Group IIC
Zone 2
Dust
Group IIIC
Zone 22
When used in hazardous areas
the special conditions of the approval must be observed
SC-M12/3GD safety clips are included in delivery and prevent inadvertent disconnection of the energized cable

This combination does not exist.

Ultrasonic Sensor Features

Diffuse Mode Sensor
Max. range 400 mm
Smooth sonic transducer face
Cylindrical housing M18
potted
Connection via M12 x 1 male
Teach range adjustable via pushbutton or adapter
Temperature compensation
Blind zone: 2.5 cm
Range: 40 cm
Resolution: 0.5 mm
Aperture angle of sonic cone: ±15 °
1 × switching output
PNP/NPN
1 × analog output
4…20 mA / 0…10 V / additional switching output
PNP/NPN
NO/NC programmable
Transmission of process value and parametrization via IO-link
ATEX II 3 G approval
Gases and vapors
Group IIC
Zone 2
Dust
Group IIIC
Zone 22
When used in hazardous areas
the special conditions of the approval must be observed
SC-M12/3GD safety clips are included in delivery and prevent inadvertent disconnection of the energized cable

Measurement Maximum	0
Case Material	304 SS
Measurement Minimum	0
Output Communication Protocol	Multiple
Country of Origin	DE
