Turck Ultrasonic Sensor, Diffuse Mode Sensor (RU200-CP40-2UP8X2T)

https://www.branom.com/web/image/product.template/171766/image_1920?unique=c26756c
(0 review)
Ultrasonic Sensor Features
  • Diffuse Mode Sensor
  • Max. range 2000 mm
  • Separate transducers for transmitter and receiver
  • Rectangular housing 40 x 40 x 166 mm
  • Connection via screw terminals
  • Terminal chamber for M20 x 1.5 cable gland
  • Teach range adjustable via button
  • Blind zone: 5 cm
  • Range: 200 cm
  • Resolution: 1 mm
  • Aperture angle of sonic cone: ±60 °
  • 2 x switching outputs
  • PNP
  • NO/NC programmable

$ 467.20 467.2 USD $ 467.20

$ 467.20

Not Available For Sale

  • Measurement Maximum
  • Case Material
  • Measurement Minimum
  • Output Communication Protocol
  • Country of Origin

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

Ultrasonic Sensor Features

  • Diffuse Mode Sensor
  • Max. range 2000 mm
  • Separate transducers for transmitter and receiver
  • Rectangular housing 40 x 40 x 166 mm
  • Connection via screw terminals
  • Terminal chamber for M20 x 1.5 cable gland
  • Teach range adjustable via button
  • Blind zone: 5 cm
  • Range: 200 cm
  • Resolution: 1 mm
  • Aperture angle of sonic cone: ±60 °
  • 2 x switching outputs
  • PNP
  • NO/NC programmable

Specifications

Measurement Maximum 0
Case Material Plastic
Measurement Minimum 0
Output Communication Protocol PNP
Country of Origin DE
