Turck Inductive Sensor, With Extended Switching Distance (NI5U-Q10S-AP6X-0.3-PSG3M)

https://www.branom.com/web/image/product.template/169832/image_1920?unique=c26756c
(0 review)
Inductive Sensor Features
  • With Extended Switching Distance
  • Rated switching distance 5 mm
  • Cable length (L) 0.3 m
  • Non-flush
  • Rectangular
  • height 10.2 mm
  • Active face
  • lateral
  • Cable outlet to all sides
  • Plastic
  • PP-GF20
  • Factor 1 for all metals
  • Increased switching distance
  • Protection class IP68
  • Resistant to magnetic fields
  • Auto-compensation protects against pre-damping
  • Flush mounted installation on up to 4 sides
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • PNP output
  • Pigtail with male end M8 x 1

$ 135.50 135.5 USD $ 135.50

$ 135.50

Not Available For Sale

  • Measurement Maximum
  • Case Material
  • Measurement Minimum
  • Output Communication Protocol
  • Input Voltage
  • Country of Origin

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

Inductive Sensor Features

  • With Extended Switching Distance
  • Rated switching distance 5 mm
  • Cable length (L) 0.3 m
  • Non-flush
  • Rectangular
  • height 10.2 mm
  • Active face
  • lateral
  • Cable outlet to all sides
  • Plastic
  • PP-GF20
  • Factor 1 for all metals
  • Increased switching distance
  • Protection class IP68
  • Resistant to magnetic fields
  • Auto-compensation protects against pre-damping
  • Flush mounted installation on up to 4 sides
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • PNP output
  • Pigtail with male end M8 x 1

Specifications

Measurement Maximum 0
Case Material Plastic
Measurement Minimum 0
Output Communication Protocol NPN
Input Voltage 10-30 VDC
Country of Origin CH
