Turck Incremental Encoder, Industrial Line (RI-10S10C-2B2500-12M23)
Representative photo. Please check item description for details.

Turck Incremental Encoder, Industrial Line (RI-10S10C-2B2500-12M23)

https://www.branom.com/web/image/product.template/170890/image_1920?unique=c26756c
(0 review)
Incremental Encoder Features
  • Industrial Line
  • Resolution
  • incremental 2500 ppr
  • Clamping flange
  • Ø 58 mm
  • Solid shaft
  • Ø 10 mm × 20 mm
  • Optical measuring principle
  • Shaft material: stainless steel
  • Protection class IP67 on housing and shaft side
  • ‐40…+85 °C
  • Max. 6000 rpm (continuous operation 3000 rpm)
  • 10…30 VDC
  • M23 male
  • 12-pin
  • Push-pull
  • with inverted signals
  • Pulse frequency max. 300 kHz
  • 2500 pulses per revolution

$ 395.42 395.42 USD $ 395.42

$ 395.42

Not Available For Sale

  • Measurement Maximum
  • Case Material
  • Measurement Minimum

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

Incremental Encoder Features

  • Industrial Line
  • Resolution
  • incremental 2500 ppr
  • Clamping flange
  • Ø 58 mm
  • Solid shaft
  • Ø 10 mm × 20 mm
  • Optical measuring principle
  • Shaft material: stainless steel
  • Protection class IP67 on housing and shaft side
  • ‐40…+85 °C
  • Max. 6000 rpm (continuous operation 3000 rpm)
  • 10…30 VDC
  • M23 male
  • 12-pin
  • Push-pull
  • with inverted signals
  • Pulse frequency max. 300 kHz
  • 2500 pulses per revolution

Specifications

Measurement Maximum 0
Case Material Aluminum
Measurement Minimum 0
