Representative photo. Please check item description for details.
VLT AutomationDrive FC 302, 30 HP / 22 KW, 380-500 VAC, 3 Phase, IP21, FC-302P22KT5E21H5XGCXXXSXXXXAXBXCXXXXDX
The VLT AutomationDrive represents a single drive concept that controls the entire range of operations from ordinary to servo like applications on any machine or production line.
- Frequency converter
- FC-302P22KT5E21H2XGXXXXSXXXXAXBXCXXXXDX
- VLT® AutomationDrive FC-302
- (P22K) 22 KW / 30 HP, Three phase
- 380 - 500 VAC, IP21 / Type 1
- RFI Filter
- No brake chopper
- Graphical Loc. Cont. Panel
- Not coated PCB, No Mains Option
- Latest release std. SW.
- No A Option, No B Option
- No C1 option, No D option
- Frame: B2
- Other options according to Model code
The VLT AutomationDrive represents a single drive concept that controls the entire range of operations from ordinary to servo like applications on any machine or production line.
- Frequency converter
- FC-302P22KT5E21H2XGXXXXSXXXXAXBXCXXXXDX
- VLT® AutomationDrive FC-302
- (P22K) 22 KW / 30 HP, Three phase
- 380 - 500 VAC, IP21 / Type 1
- RFI Filter
- No brake chopper
- Graphical Loc. Cont. Panel
- Not coated PCB, No Mains Option
- Latest release std. SW.
- No A Option, No B Option
- No C1 option, No D option
- Frame: B2
- Other options according to Model code
Specifications
| AC Drive: Brand | Danfoss |
| AC Drive: Series | FC-302 |
| AC Drive: Power Rating | 3 Phase |
| AC Drive: Output | 30 HP / 22 KW |
| AC Drive: Voltage | 380-500 VAC |
| AC Drive: IP Rating | IP21 |
