Representative photo. Please check item description for details.
VLT AutomationDrive EZ FC-321 Series, 7.5 HP / 5.5 KW, 380-500 VAC, 3 Phase, IP20 / Chassis, FC-321P5K5T5E20H2BGXXXXSXXXXAXBXCXXXXDX
- Product Group: (FC-) VLT® AutomationDrive EZ
- VLT Series: 321
- Power Rating: (P5K5) (P5K5) 5.5 KW / 7.5 HP
- Voltage: (T5) Three phase 380-500 VAC
- Enclosure: (E20) IP20 / Chassis
- RFI Filter: (H2) RFI Class A2 (C3)
- Brake - Safe Stop: (B) Brake chopper
- LCP: (G) Graphical Local Control Panel
- Coating PCB: (X) Not coated PCB
- Mains Option: (X) No Mains Option
- Adaptation A: (X) Standard Cable Entries
- Adaptation B: (X) No adaptation
- Software Release: (SXXX) Latest release - std. software
- Software Language Pack: (X) Standard Language Pack
- A Option: (AX) No A Option
- B Option: (BX) No B Option
- C0 Option: (CX) No C0 option
- C Option Software: (XX) No software option
- D Option: (DX) No D option
- Frame Size: A3
- Continuous Current (HO) [A] 3x380-440VAC.: 13
- Intermittent Current (HO) [A] 3x380-440VAC.: 20.8
- Continuous Current (HO) [A] 3x440-500VAC: 11
- Intermittent Current (HO) [A] 3x440-500VAC: 17.6
- Power Loss HO [W] 3x380-440VAC.: 187
- Power Loss HO [W] 3x440-500VAC: 187
- kVA: 9.01
- Product Group: (FC-) VLT® AutomationDrive EZ
- VLT Series: 321
- Power Rating: (P5K5) (P5K5) 5.5 KW / 7.5 HP
- Voltage: (T5) Three phase 380-500 VAC
- Enclosure: (E20) IP20 / Chassis
- RFI Filter: (H2) RFI Class A2 (C3)
- Brake - Safe Stop: (B) Brake chopper
- LCP: (G) Graphical Local Control Panel
- Coating PCB: (X) Not coated PCB
- Mains Option: (X) No Mains Option
- Adaptation A: (X) Standard Cable Entries
- Adaptation B: (X) No adaptation
- Software Release: (SXXX) Latest release - std. software
- Software Language Pack: (X) Standard Language Pack
- A Option: (AX) No A Option
- B Option: (BX) No B Option
- C0 Option: (CX) No C0 option
- C Option Software: (XX) No software option
- D Option: (DX) No D option
- Frame Size: A3
- Continuous Current (HO) [A] 3x380-440VAC.: 13
- Intermittent Current (HO) [A] 3x380-440VAC.: 20.8
- Continuous Current (HO) [A] 3x440-500VAC: 11
- Intermittent Current (HO) [A] 3x440-500VAC: 17.6
- Power Loss HO [W] 3x380-440VAC.: 187
- Power Loss HO [W] 3x440-500VAC: 187
- kVA: 9.01
Specifications
| AC Drive: Brand | Danfoss |
| AC Drive: Series | FC-321 |
| AC Drive: Power Rating | 3 Phase |
| AC Drive: Output | 7.5 HP / 5.5 KW |
| AC Drive: Voltage | 380-500 VAC |
| AC Drive: IP Rating | IP20 |
