Turck Inductive Sensor, With Switching Distance (BI50-Q80-Y1X-0.2-RS4.21T)
Representative photo. Please check item description for details.

Turck Inductive Sensor, With Switching Distance (BI50-Q80-Y1X-0.2-RS4.21T)

https://www.branom.com/web/image/product.template/165232/image_1920?unique=c26756c
(0 review)
Inductive Sensor Features
  • With Switching Distance
  • Rated switching distance 50 mm
  • Cable length (L) 0.2 m
  • Flush
  • Rectangular
  • height 40 mm
  • Active face on top
  • Plastic
  • PBT‐GF30‐V0
  • Large coverage
  • DC 2-wire
  • nom. 8.2 VDC
  • Output acc. to DIN EN 60947-5-6 (NAMUR)
  • Cable with connector M12 x 1
  • ATEX category II 2 G
  • Ex zone 1
  • ATEX category II 1 D
  • Ex zone 20
  • SIL2 (Low Demand Mode) acc. to IEC 61508
  • PL c acc. to ISO 13849-1 at HFT0
  • SIL3 (All Demand Mode) acc. to IEC 61508
  • PL e acc. to ISO 13849-1 with redundant configuration HFT1

$ 312.40 312.4 USD $ 312.40

$ 312.40

Not Available For Sale

  • Case Material
  • Measurement Minimum

This combination does not exist.

Contact Us
Product Datasheets

Datasheet 1

Share

Inductive Sensor Features

  • With Switching Distance
  • Rated switching distance 50 mm
  • Cable length (L) 0.2 m
  • Flush
  • Rectangular
  • height 40 mm
  • Active face on top
  • Plastic
  • PBT‐GF30‐V0
  • Large coverage
  • DC 2-wire
  • nom. 8.2 VDC
  • Output acc. to DIN EN 60947-5-6 (NAMUR)
  • Cable with connector M12 x 1
  • ATEX category II 2 G
  • Ex zone 1
  • ATEX category II 1 D
  • Ex zone 20
  • SIL2 (Low Demand Mode) acc. to IEC 61508
  • PL c acc. to ISO 13849-1 at HFT0
  • SIL3 (All Demand Mode) acc. to IEC 61508
  • PL e acc. to ISO 13849-1 with redundant configuration HFT1

Specifications

Case Material Plastic
Measurement Minimum 0
