AVENTICS NR01 Series Shut-Off Valve, Ø 4 Push-In Fitting, Brass, NBR Seal
AVENTICS Series NR01, Thanks to an array of connection options, the NR non-return valves can be screwed in separately and are also suitable for direct installation in piping.
Features
- Compressed air connection 1: Ø 4
- Compressed air connection type 1: push-in fitting
- Compressed air connection type 2: push-in fitting
- Type: Poppet valve
- Compressed air connection 2: Ø 4
- Nominal flow Qn 1 to 2: 195 l/min
- Working pressure min.: 0.2 bar
- Working pressure max: 10 bar
- Min. ambient temperature: -20 °C
- Max. ambient temperature: 70 °C
- Min. medium temperature: -20 °C
- Max. medium temperature: 70 °C
- Medium: Compressed air
- Weight: 0.017 kg
- Housing material: Brass
- Seal material: Acrylonitrile butadiene rubber:
